Soleus Muscle – Attachments, Actions & Innervation

Author: Scott A. Sheffield MS

Last update:

The soleus muscle is a leg muscle located on the calf, at the posterior aspect of the leg.

image descriptionSoleus Muscle

Soleus Muscle attached to the lower limb with other muscles
Soleus Muscle attached to the lower limb with other muscles
Soleus Muscle attached to the lower limb with other muscles
Soleus Muscle attached to the lower limb alone
1
2
3
4

image descriptionAttachments of Soleus Muscle: Origin & Insertion

Origin: (proximal attachments):
a. Proximal half of posterior surface of tibia along soleal line.
b. proximal 1/3 of posterior fibula.

Insertion: (distal attachments):
Posterior calcaneus via calcaneal tendon.

Soleus Muscle attached to the lower limb with other muscles
Soleus Muscle attached to the lower limb alone
Soleus Muscle - Origin and Insertion
1
2
3

Actions of Soleus Muscle on the foot:

image descriptionPlantar flexes foot.

Need a hand learning the muscles of the leg? Look no further than these quizzes, diagrams and labelling exercises.

Nerve to Muscle and its Spinal Segment:

Tibial nerve (S1, S2).

Overview:

Muscles That Act On Foot & Ankle (From Post. Leg Comp.)

Soleus Muscle - Test yourself
Soleus Muscle - Test yourself 1
Soleus Muscle - Test yourself 2
Soleus Muscle - Test yourself 3
Soleus Muscle - Test yourself 4
Soleus Muscle - Test yourself 5
Soleus Muscle - Test yourself 6
Soleus Muscle - Test yourself 7
Soleus Muscle - Test yourself 8
Soleus Muscle - Test yourself 9
Soleus Muscle - Test yourself 10
Soleus Muscle - Test yourself 11
Soleus Muscle - Test yourself 12
Soleus Muscle - Test yourself 13
